SD12-102

Shielded Inductors

SD12-102 General Description



* Six sizes of shielded drum core inductors with low profiles (as low as 1.0mm) and high power density

* Inductance range from .47uH to 1000uH

* Current range from 6.00 to 0.088 Amps

* Ferrite shielded, low EMI Applications

* Digital cameras, CD players, cellu.

SD12-102 Datasheet (404.86 KB)

Preview of SD12-102 PDF

Datasheet Details

Part number:

SD12-102

Manufacturer:

Cooper Electronic

File Size:

404.86 KB

Description:

Shielded inductors.
