DAC-1412
FEATURES n 14-bit resolution n 125MSPS conversion rate n 35 ns settling time to ±0.05% n Operates from single +3V to +5V supply n Humidity and stress resistant ceramic LCC package for -QL and /883 models n -40°C to +105°C and -55°C to +125°C operating temperature ranges n 100% testing over temperature n )JHI3FMQSPDFTTøPXCVSOJOFOWJSPONFOUBMMPUBOE"5& traceability n Low power, 150m W (5V supply) 76m W (+3V supply) n Internal +1.2V temperature pensated bandgap reference with an external reference option n Outstanding dynamic performance n Guaranteed monotonicity over temperature n -4#%JòFSFOUJBM/PO-JOFBSJUZ .BY
PWFSUFNQFSBUVSF n ±2 LSB Integral Non-Linearity (Max) over temperature n TSSOP package (SE,SM models), Pb-free Ro HS pliant
PRODUCT OVERVIEW
The 14-bit DAC-1412 is one in a series of high speed pin to pin patible 8 to 14 bit D/A’s from DATEL. This D/A DPOWFSUFSPòFSTVQUP.414DPOWFSTJPOSBUFGSPNBTFH mented current source topology that is built on an...
