DCP55 Datasheet, Transistor, DIODES

DCP55 Features

• Transistor
• Epitaxial Planar Die Construction
• Complementary PNP Type Available (DCP52)
• Ideally Suited for Automated Assembly Processes
• Ideal for Medium Power

PDF File Details

Part number:

DCP55

Manufacturer:

DIODES ↗

File Size:

297.98kb

Download:

📄 Datasheet

Description:

Npn surface mount transistor.

DCP55 Application

• Applications
• Lead Free By Design/RoHS Compliant (Note 1)
• "Green" Device (Note 2) Mechanical Data
• Case: SOT-223
