DMP4006SPSWQ Datasheet, Mosfet, DIODES

DMP4006SPSWQ Features

• Mosfet
• 100% Unclamped Inductive Switch (UIS) Test in Production
• Low On-Resistance
• Fast Switching Speed
• Wettable Flank for Improved Optical Inspections <

PDF File Details

Part number:

DMP4006SPSWQ

Manufacturer:

DIODES ↗

File Size:

367.01kb

Download:

📄 Datasheet

Description:

40v p-channel enhancement mode mosfet. and Applications This MOSFET is designed to meet the stringent requirements of automotive applications. It is qualified to AEC-Q101,

DMP4006SPSWQ Application

• Applications This MOSFET is designed to meet the stringent requirements of automotive applications. It is qualified to AEC-Q101, supported by a PPAP
