BR258W

TECHNICAL SPECIFICATIONS OF SINGLE-PHASE SILICON BRIDGE RECTIFIER

Dc Components

Image	Manufacturer	P/N	B2B MPN	Description	Distributor	Stock	Quantity	Price	Buy Now
	Rectron Semiconductor	BR258W	BR258W	Bridge Rectifiers 25A 800V-Wire Leads	Mouser Electronics	0	400 units	$2.82

Download Datasheet (429.53 KB)

BR258W Datasheet Preview — Preview of BR258W Datasheet

Datasheet Details

Part number:

BR258W

Manufacturer:

Dc Components

File Size:

429.53 KB

Description:

Technical specifications of single-phase silicon bridge rectifier.
DC COMPONENTS CO., LTD. R BR2505W THRU BR2510W RECTIFIER SPECIALISTS TECHNICAL SPECIFICATIONS OF .
SINGLE-PHASE SILICON BRIDGE RECTIFIER VOLTAGE RANGE - 50 to 1000 Volts CURRENT - 25 Amperes FEATURE.

✔ BR258W Features

Plastic case with heatsink for Maximum Heat Dissipation
Surge overload ratings-400 Amperes
Low forward voltage drop BR-25W METAL HEAT SINK TYP MECHANICAL DATA
