DL4745A TECHNICAL SPECIFICATIONS OF GLASS SILICON ZENER DIODES

DL4745A Description

DC COMPONENTS CO., LTD.R DL4728A THRU DL4754A RECTIFIER SPECIALISTS TECHNICAL SPECIFICATIONS OF GLASS SILICON ZENER DIODES .

DL4745A Features

* Voltage Range:3.3V to 39V
* Double slug type construction DL-41 MECHANICAL DATA
* Case: Glass sealed case
* Terminals:Solder plated, solderable per MIL-STD-750, Method 2026
* Polarity: Color band denotes cathode end
* Mounting position: Any
* Weight: 0.35 gram 5.0±0.2

📥 Download Datasheet

Preview of DL4745A PDF
datasheet Preview Page 2

Datasheet Details

Part number
DL4745A
Manufacturer
Dc Components
File Size
188.35 KB
Datasheet
DL4745A_DcComponents.pdf
Description
TECHNICAL SPECIFICATIONS OF GLASS SILICON ZENER DIODES
