IA0505S-1W Datasheet, converter equivalent, Delus

IA0505S-1W Features

• Converter u Operating temperature: -40 to +85℃ u ±5/±9/±12/±15Vdc multiple voltage output u International standard pin-out u 100% burn-in u No external component required u UL94V-0 package u RoHS

PDF File Details

Part number:

IA0505S-1W

Manufacturer:

Delus

File Size:

720.87kb

Download:

📄 Datasheet

Description:

1500vdc isolated & regulated dual output dc-dc converter. IA-1W/2W series dc/dc converters are specially designed for the application of the power supply which is isolated from the input sour

IA0505S-1W Application

• Applications EMI 1500 Vdc 3000 Vdc High Power Density Fuctional
  Diagram Vin GND IA/IE-xW Reg +Vo 0V
