B130 - 1.0A SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER

Description

This Schottky barrier rectifier is designed to meet the general requirements of commercial applications.

Polarity protection diodes Re-circulating diodes Switching diodes

Features

Guard Ring Die Construction for Transient Protection.
Ideally Suited for Automated Assembly.
Low Power Loss, High Efficiency.
Surge Overload Rating to 30A Peak.
For Use in Low-Voltage, High-Frequency Inverters, Free Wheeling, and Polarity Protection.

Diodes Incorporated

📥 Download Datasheet

Datasheet Details

Part number	B130
Manufacturer	DIODES Incorporated
File Size	403.16 KB
Description	1.0A SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
Datasheet	B130 Datasheet
Additional preview pages of the B130 datasheet.
