TZX5V1 500mW EPITAXIAL PLANAR ZENER DIODE

TZX5V1 Description

TZX2V4 - TZX36C 500mW EPITAXIAL PLANAR ZENER DIODE .

TZX5V1 Features

* Planar Die Construction 500mW Power Dissipation on FR-4 PCB General Purpose, Medium Current A PRELIMINARY B A Mechanical Data
* Case: DO-35, Glass Leads: Solderable per MIL-STD-202, Method 208 Marking: Type Number Polarity: Cathode Band Weight: 0.35

📥 Download Datasheet

Preview of TZX5V1 PDF
datasheet Preview Page 2 datasheet Preview Page 3
