EH16A, EH11A, 1A LOW DROPOUT LINEAR REGULATOR

NOT RECOMMENDED FOR NEW DESIGN USE AZ1117C or AZ1117I Pb Lead-Free AZ1117 1A LOW DROPOUT LINEAR REGULATOR .
The AZ1117 is a series of low dropout three-terminal regulators with a dropout of 1.

datasheet Preview Page 1 from Datasheet4u.com

EH11A-Diodes.pdf

EH16A Datasheet Preview — This datasheet PDF includes multiple part numbers: EH16A, EH11A. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

EH16A, EH11A

Manufacturer:

DIODES ↗

File Size:

1.03 MB

Description:

1A LOW DROPOUT LINEAR REGULATOR

Note:

This datasheet PDF includes multiple part numbers: EH16A, EH11A.
Please refer to the document for exact specifications by model.

Features

* Low Dropout Voltage: 1.15V at 1A Output Current
* Trimmed Current Limit
* On-chip Thermal Shutdown
* Three-terminal Adjustable or Fixed 1.2V, 1.5V, 1.8V, 2.5V, 2.85V, 3.3V, 5.0V
* Operation Junction Temperature: -40 to +125oC
* Lead-Free Packages: SOT223, SOT89, TO220-3, TO

Applications

* PC Motherboard
* LCD Monitor
* Graphic Card
* DVD-video Player
* NIC/Switch
* Telecom Equipment
* ADSL Modem
* Printer and other Peripheral Equipment Notes: 1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS), 2011/65/EU (RoHS 2) & 2015/863/EU (RoHS 3
