MBR5200

HIGH VOLTAGE POWER SCHOTTKY RECTIFIER

MBR5200 Features

* Low Forward Voltage: 0.95V @ +25°C

* High Surge Current Capacity

* +150°C Operating Junction Temperature

* 5A Total

* Guard-Ring for Stress Protection

* Pb-Free Package is Available

* DO-27, DO-27 (C) and DO-27 (Type YJ)

* Lead-Free F

MBR5200 General Description

The MBR5200 is a high-voltage Schottky rectifier suited for switch mode power supplies and other power converters. This device is intended for use in medium voltage operation, and particularly, in high-frequency circuits where low switching losses and low noise are required. The MBR5200 is available.

MBR5200 Datasheet (606.74 KB)

Preview of MBR5200 PDF

Datasheet Details

Part number:

MBR5200

Manufacturer:

DIODES ↗

File Size:

606.74 KB

Description:

High voltage power schottky rectifier.
NOT RECOMMENDED FOR NEW DESIGN - NO ALTERNATE PART Pb MBR5200 HIGH VOLTAGE POWER SCHOTTKY RECTIFIER Product Summary VRRM (V) 200 IO (A) 5 VF (.
