PAM8303C Datasheet, Amplifier, Diodes

PAM8303C Features

• Amplifier like 90% efficiency and small PCB area make the PAM8303C Class-D amplifier ideal for cellular handsets. The filterless architecture requires no external output filter, fewer external co

PDF File Details

Part number:

PAM8303C

Manufacturer:

DIODES ↗

File Size:

769.17kb

Download:

📄 Datasheet

Description:

3w filterless mono class-d audio power amplifier. The PAM8303C is a 3W mono filterless Class-D amplifier with high PSRR and differential input that eliminate noise and RF rectificatio

PAM8303C Application

• Applications
• Cellular Phones/Smart Phones
• MP4/MP3
• GPS
• Digital Photo Frame
• Electronic Dictionary
