S2KF, S2KF-E SURFACE MOUNT RECTIFIER

Description

E-DA SEMICONDUCTOR RoHS Compliant Product S2AF~S2MF SURFACE MOUNT RECTIFIER VOLTAGE 50 to 1000 Volts CURRENT 2.0 Amperes 0.146(3.70) 0.136(3.45) 0.

📥 Download Datasheet

S2KF Datasheet Preview — This datasheet PDF includes multiple part numbers: S2KF, S2KF-E. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: S2KF, S2KF-E
Manufacturer: E-DA SEMICONDUCTOR
File Size: 135.25 KB
Datasheet: S2KF-E-DASEMICONDUCTOR.pdf
Description: SURFACE MOUNT RECTIFIER
Note: This datasheet PDF includes multiple part numbers: S2KF, S2KF-E.
Please refer to the document for exact specifications by model.

Features

* Plastic package has Underwriters Laboratory Flammability Classification 94V-O

Applications

* Low profile package
* Built-in strain relief
* Easy pick and place
* Glass passivated iunction
* Both normal and Pb free product are available : Normal : 80~95% Sn, 5~20% Pb Pb free: 98.5% Sn above MECHANICAL DATA Case: JEDEC SMBF molded plastic Terminals:So
