Part number:
21DQ09
Manufacturer:
EIC
File Size:
85.02 KB
Description:
Schottky barrier diode.
21DQ09
EIC
85.02 KB
Schottky barrier diode.
* :
* High surge capability
* High efficiency
* Low power loss
* Low forward voltage drop
* Pb / RoHS Free MECHANICAL DATA :
* Case : DO-41 Molded plastic
* Epoxy : UL94V-O rate flame retardant
* Lead : Axial lead solderable per MIL-STD-202, Method 208 guaranteed
