BN547 STBN547

BN547 Description

www.DataSheet4U.com STBN06I - STBN5D0 VBR : 6.8 - 200 Volts PPK : 1500 Watts .

BN547 Features

* :
* 1500W surge capability at 1ms
* Excellent clamping capability
* Low zener impedance
* Fast response time : typically less then 1.0 ps from 0 volt to VBR(min. )
* Typical IR less then 1µA above 10V
* Pb / RoHS Free SURFACE MOUNT BIDIRECTIONAL TRANSIENT VOLTAGE SUPPRESSOR S

BN547 Applications

* For Uni-directional altered the third letter of type from "B" to be "U". Electrical characteristics apply in both directions MAXIMUM RATINGS Rating at 25 °C ambient temperature unless otherwise specified. Rating Peak Power Dissipation at Ta = 25 °C, Tp=1ms (Note1) Steady State Power Dissipation at

📥 Download Datasheet

Preview of BN547 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
BN547
Manufacturer
EIC
File Size
105.37 KB
Datasheet
BN547_EIC.pdf
Description
STBN547
