STUP091

(STUP06I - STUP5G4) SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR

EIC

Download Datasheet (56.13 KB)

STUP091 Datasheet Preview — Preview of STUP091 Datasheet

Datasheet Details

Part number:

STUP091

Manufacturer:

EIC

File Size:

56.13 KB

Description:

(stup06i - stup5g4) surface mount transient voltage suppressor.
www.DataSheet4U.com STUP06I - STUP5G4 VBR : 6.8 - 440 Volts PPK : 400 Watts FEATURES : * 400W surge.
capability at 1ms * Excellent clamping capability * Low zener impedance * Fast response time : typi.

✔ STUP091 Features

:
400W surge capability at 1ms
Excellent clamping capability
Low zener impedance
Fast response time : typically less then 1.0 ps from 0 volt to VBR(min.)
Typica

✔ STUP091 Application

For bi-directional altered the third letter of type from "U" to be "B". Electrical characteristics apply in
