Part number:
SZ1568
Manufacturer:
EIC
File Size:
26.40 KB
Description:
Surface mount silicon zener diodes.
* :
* Complete Voltage Range 3.3 to 200 Volts
* High peak reverse power dissipation
* High reliability
* Low leakage current MECHANICAL DATA
* Case : SMA (DO-214AC) Molded plastic
* Epoxy : UL94V-O rate flame retardant
* Lead : Lead formed for Surface mount
* Polarity :
SZ1568
EIC
26.40 KB
Surface mount silicon zener diodes.
