ETA5052
DESCRIPTION
ETA5052 is a low-dropout (LDO) low-power linear voltage regulator features high power-supply rejection ratio (PSRR), ultralow-noise, fast startup, and excellent line and load transient responses. Its PSRR can be as high as 80d B and its noise level can be as low as 30μVRMS of output voltage noise at 2.8V output with a 0.1μF bypass capacitor. Therefore, ETA5052 is an ideal power supply for noise-sensitive applications such as RF transmissions, cellphones, CMOS sensors and audios etc. ETA5052’s output voltage is adjustable through external feedback resistors and is housed in SOT23-6 package.
FEATURES
- High PSRR, 80 d B at 10Hz,70d B at 10Kz
- Low Noise, 30μVRMS
- Stable With a Wide Range of Ceramic
Capacitor larger than 1μF
- Excellent Load and Line Transient
Response
- Very Low Dropout Voltage
- 300m A output current
APPLICATIONS
- RF power
- Sensors
- Audio
TYPICAL APPLICATION
ORDERING INFORMATION
PART No. PACKAGE
ETA5052V0S2G SOT23-6
TOP MARK
DCYW
Pcs/Reel
