CBB13102 Polypropylene Film Capacitor

CBB CB B 13{{PPN} PPN } （） CBB13 Po yp rop y l en e iFFilm ap a c it or PPolypropylene ol m l CCapacitor CBB CBB13 CB B 13 are non-inductively wound with metallized Polypropylene film as dielectric and aluminum foil as the electrode with copperclad steel leads and epoxy resin coated SSPECIFICATIONS P EC IF ICA T I ON S Rated voltage：100V,200V/250V,400V,630V,1000V Capacitance range:0.0010-1UF Capacitance tolerance: ±5%(J) ±10%(k) Operating temperature：40/85/21 Voltage proof:2UR(5s) Dissipation .

CBB13102 Features

* 1.Very low loss at high frequency,suitable for high current 2.Excellent frequency and temperature characteristics 3.High in sulation resistance,self-healing effect 4.Widely used in high frequency,DC,AC and pulse circuits http://www.Datasheet4U.com CBB13 CB B 13 50/100VDC Rated Cap. Part Number 10
