KBPC100 - 3.0 AMPERE SINGLE-PHASE SILICON BRIDGE RECTIFIER

Datasheet Summary

Features

  • Plastic material has Underwriters Laboratory flammability classification 94V-0. Low leakage. Surge overload rating - 50 amperes peak. Ideal for printed circuit boards. Exceeds environmental standards of MIL - STD - 19500. Ø 3.8 + 11.3 10.3 ~ 15.8 14.7 2.7 1.7 ~ Ø 0.8 ± 19.0 min 6.9 5.8.

📥 Download Datasheet

Datasheet preview – KBPC100

Datasheet Details

Part number KBPC100
Manufacturer ETC
File Size 119.38 KB
Description 3.0 AMPERE SINGLE-PHASE SILICON BRIDGE RECTIFIER
Datasheet download datasheet KBPC100 Datasheet
Additional preview pages of the KBPC100 datasheet.

📁 Similar Datasheet

  • KBPC1000 - 10A SINGLE PHASE BRIDGE RECTIFIER (WON-TOP)
  • KBPC1000 - SINGLE PHASE 10 AMPS. SILICON BRIDGE RECTIFIERS (Jinan Gude Electronic Device)
  • KBPC1000 - 10A HIGH CURRENT BRIDGE RECTIFI (SANGDEST MICROELECTRONICS)
  • KBPC1000-G - Fast Recovery Bridge Rectifier (SENSITRON SEMICONDUCTOR)
  • KBPC10005 - SINGLE-PHASE GLASS PASSIVATED BRIDGE RECTIFIERS (Kingtronics)
  • KBPC10005 - Bridge Rectifier (Formosa MS)
  • KBPC10005 - Bridge Rectifier (Yangzhou Yangjie)
  • KBPC10005 - 10.0 A Single-Phase Silicon Bridge Rectifier (SEP ELECTRONIC)
  • KBPC10005 - SINGLE-PHASE BRIDGE RECTIFIER (Suntan)
  • KBPC10005 - GLASS PASSIVATED SINGLE-PHASE BRIDGE RECTIFIER (STS)
Other Datasheets by ETC
  • KBPC103 - 3.0 AMPERE SINGLE-PHASE SILICON BRIDGE RECTIFIER
  • KBPC103 - 3.0 AMPERE SINGLE-PHASE SILICON BRIDGE RECTIFIER
  • KBP301 - 3.0A BRIDGE RECTIFIER
  • KBP301 - SINGLE PHASE 3.0 AMP BRIDGE RECTIFIERS
  • KBP302 - 3.0A BRIDGE RECTIFIER
  • KBP302 - SINGLE PHASE 3.0 AMP BRIDGE RECTIFIERS
  • KBP303 - 3.0A BRIDGE RECTIFIER
  • KBP303 - SINGLE PHASE 3.0 AMP BRIDGE RECTIFIERS

Full PDF Text Transcription

Click to expand full text
E-MAIL: info@angliac.com WEB: www.angliac.com KBPC100 SERIES 3.0 AMPERE SINGLE-PHASE SILICON BRIDGE RECTIFIER VOLTAGE RANGE 50 to 1000 Volts CURRENT 3 Amperes FEATURES Plastic material has Underwriters Laboratory flammability classification 94V-0. Low leakage. Surge overload rating - 50 amperes peak. Ideal for printed circuit boards. Exceeds environmental standards of MIL - STD - 19500. Ø 3.8 + 11.3 10.3 ~ 15.8 14.7 2.7 1.7 ~ Ø 0.8 ± 19.0 min 6.9 5.8 MECHANICAL DATA Case : : : Terminals : : Polarity : Weight : Reliable low cost construction utilizing moulded plastic technique results in inexpensive product. Leads, solderable per MIL - STD - 202, Method 208. Polarity symbols printed on body. 0.13 ounce, 3.8 grams.
