V800ME06, VOLTAGE CONTROLLED OSCILLATOR

V802ME06 9939 Via Pasar * San Diego, CA 92126 TEL (619) 621-2700 FAX (619) 621-2722 VOLTAGE CONTROLLED OSCILLATOR Rev A1 PHASE NOISE (1 Hz .

datasheet Preview Page 1 from Datasheet4u.com

V800ME06_ETC.pdf

V800ME06 Datasheet Preview — Preview of V800ME06 PDF

Datasheet Details

Part number:

V800ME06

Manufacturer:

ETC

File Size:

163.23 KB

Description:

VOLTAGE CONTROLLED OSCILLATOR

Features

* Frequency Range: 2225 - 2350 MHz
* Tuning Voltage: 1-8 Vdc

Applications

* PCS Basestations
* Earthstations
* Satellite Modems PERFORMANCE SPECIFICATIONS Oscillation Frequency Range Phase Noise @ 10 kHz offset (1 Hz BW, typ. ) Harmonic Suppression (2nd, typ. ) Tuning Voltage Tuning Sensitivity (avg. ) Power Output Load Impedance Input Capacitance (ma
