AV60C-048L-033F15 Datasheet - Emerson

AV60C-048L-033F15 DC-DC / Industry Standard Isolated Half Brick

Astec Industry Standard 50-150 Watts AV60C Total Power: Input Voltages: No. of Outputs: 50-150 Watts 48V Single Electrical Specs Input Input range Input Surge Efficiency 36-75 VDC 100V / 100ms 83%@5V Output Load regulation Line regulation Ripple and noise Output voltage adjust range Transient Response Industry standard pin-out & performance 100°C baseplate temperature (no derating) Positive and negative enable function Low output ripple and noise Remo.

AV60C-048L-033F15 Features

* Control Voltage Adjust Enable 90 to 110% TTL compatible (positive & negative enable options) Environmental Operating case temperature range: -40°C to +100°C Storage temperature: -55°C to +125°C MTBF: >2 million hours Safety UL CSA TUV UL1950 CSA22.2-950 EN60950 34 America’s (USA): 1-888-41-ASTE

AV60C-048L-033F15 Datasheet (298.06 KB)
