LES40A48-1V5RAJ Datasheet - Emerson

LES40A48-1V5RAJ DC-DC / Industry Standard Isolated Eighth Brick

Eighth-Brick Series Single output DC/DC CONVERTERS High Current, High Efficiency, Low Profile NEW Product 1 Ultra-high efficiency topology Industry standard eighth brick footprint (identical to quarter-brick pinout) Low profile through-hole version Low profile with 38% space savings over other quarter-brick brick converters Wide ambient temperature range, -40 ºC to +85 ºC 80% to 110% output trim M.

LES40A48-1V5RAJ Features

* an input voltage range of 18 Vdc to 36 Vdc and 36 Vdc to 75 Vdc and is available with output voltages of 1.2 V, 1.5 V 1.8 V, 2.5 V, 3.3 V and 5.0 V. The output voltage is adjustable from 80% to 110% of the nominal value. The series also has a remote ON/OFF capability. Overcurrent, overvoltage and ov

LES40A48-1V5RAJ Datasheet (111.97 KB)

Preview of LES40A48-1V5RAJ PDF

Datasheet Details

Part number:

LES40A48-1V5RAJ

Manufacturer:

Emerson

File Size:

111.97 KB

Description:

Dc-dc / industry standard isolated eighth brick.
