EBRT20L80T
Features
‧Schottky barrier diodes ‧Low forward voltage drop ‧Low leakage current ‧Moisture sensitivity: level 1, per J-STD-020 ‧Solder dip 260 °C, 10 s ‧Low profile ‧Heatsink design
Ordering Information
Part No. EBRT20L80T EBRT20L80T -H
Remark General Halogen Free
Package Packing TO-277 5000 / Reel
Maximum Ratings (TA=25°C unless otherwise noted)
PARAMETER Maximum repetitive peak reverse voltage Maximum RMS voltage Maximum DC blocking voltage Maximum average forward rectified current
SYMBOL VRRM VRMS VDC IF
Peak forward surge current, 8.3ms single half sine-wave superimposed on rated load
IFSM
Maximum Instantaneous Forward Voltage
IF=3A @ 25°C
IF=20A @ 25°C
Maximum DC Reverse Current @ TA=25°C at Rated DC Blocking Voltage @ TA=100°C
Typical Junction Capacitance(NOTE1) Typical Thermal Resistance Operating Temperature Range Storage Temperature Range Marking Code
Cj RθJC
TJ TSTG
NOTES:
1.Measured at 1.0MHZ and applied reverse voltage of 4.0V DC
Excellent Schottky...
