EBRT3E45AF - Schottky Barrier Rectifiers

EBRT3E45AF Description

EBRT3E45AF Schottky Barrier Rectifiers DO-221AC(SMAF) .

EBRT3E45AF Features

* ‧High current capability ‧High surge current capability ‧Low reverse current ‧Component in accordance to RoHS 2002/95/EC Primary Characteristics IF 3 A VRRM 45 V IFSM 30 A VF 0.43 V TJ max 150 °C Mechanical Data ‧Case: DO-221AC(SMAF) ‧Case Material: Molded Plastic. UL Flammability C

📥 Download Datasheet

Preview of EBRT3E45AF PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
EBRT3E45AF
Manufacturer
Eris
File Size
357.94 KB
Datasheet
EBRT3E45AF-Eris.pdf
Description
Schottky Barrier Rectifiers
