SM4030CD2, SM4020CD2 Schottky Barrier Rectifiers

Eris

Description

Α SM40xxxCD2 SERIES Schottky Barrier Rectifiers D2-PAK Primary Characteristics IF 40 A VRRM 40~200 V IFSM 250 A IF=20A @ VF 0.65, 0.75,.

📥 Download Datasheet

SM4030CD2 Datasheet Preview — This datasheet PDF includes multiple part numbers: SM4030CD2, SM4020CD2. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: SM4030CD2, SM4020CD2
Manufacturer: Eris
File Size: 339.83 KB
Datasheet: SM4020CD2-Eris.pdf
Description: Schottky Barrier Rectifiers
Note: This datasheet PDF includes multiple part numbers: SM4030CD2, SM4020CD2.
Please refer to the document for exact specifications by model.

Features

* ‧Guard Ring for Over Voltage Protection ‧High Forward Surge Capability ‧High Frequency Operation Mechanical Data ‧Case：D2-PAK ‧Case Material：Molded Plastic, UL Flammability Classification Rating 94V-0 ‧Terminals：Matte Tin Finish annealed over copper Leadframe. Solderable per MIL-STD-202 Ordering I

Applications

* shall assume all risks of such use and will agree to hold Eris and all the companies whose products are represented on Eris website, harmles
