16C2850 - DUAL UART WITH 128-byte FIFOs AND RS-485 HALF DUPLEX CONTROL

Datasheet Summary

Description

The XR16C2850 (2850) is a dual universal asynchronous receiver and transmitter (UART).

The 2850 provides enhanced UART functions with 128 byte FIFO, automatic RS-485 half duplex control, a modem control interface, and data rates up to 1.5 Mbps.

Features

  • may be tailored by external software to meet specific user requirements. An internal loopback capability allows onboard diagnostics. Independent programmable baud rate generators are provided to select transmit and receive clock rates up to 1.5 Mbps. The baud rate generator can be configured for either crystal or external clock input. The 2850 is available in a 40-pin PDIP, 44-pin PLCC, and 48-pin TQFP packages. The 40 pin package does not offer TXRDY and RXRDY pins (DMA Signal monitoring). Othe.
