1N6274, 1N6267 - 1500W Unidirectional and Bidirectional Transient Voltage Suppressor Diodes

Name: 1N6274
SKU: 1N6274-1275190

FAGOR

The 1N6274 by FAGOR is a 1500W Unidirectional and Bidirectional Transient Voltage Suppressor Diodes. Below is the official datasheet preview.

📥 Download Datasheet

1N6274 1500W Unidirectional and Bidirectional Transient Voltage Suppressor Diodes by FAGOR - Datasheet Preview — Official preview page of the **1N6274** 1500W Unidirectional and Bidirectional Transient Voltage Suppressor Diodes datasheet (FAGOR).

Datasheet Details

Part number	1N6274, 1N6267
Manufacturer	FAGOR
File Size	524.15 KB
Description	1500W Unidirectional and Bidirectional Transient Voltage Suppressor Diodes
Datasheet	1N6267-FAGOR.pdf
Note	This datasheet PDF includes multiple part numbers: 1N6274, 1N6267. Please refer to the document for exact specifications by model.
Additional preview pages of the 1N6274 datasheet.

1N6274 Product details

Features

Glass passivated chip junction Hyperectifier structure for high reliability Cavity-free glass-passivated junction 1500 W peak pulse power capability with a 10/1000 µs waveform, repetitive rate (duty cycle): 0.01 % Excellent clamping capability Very fast response time Low incremental surge resistance Available in uni-directional and bi-directional Solder dip 260ºC, 10s AEC-Q101 qualified Component in accordance to RoHS 2011/65/EU and WEEE 2002/96/EC Meets MSL level 1, per.
