1N914BWT
Features
- Fast Switching Diode (Trr <4.0nsec)
- Flat Lead, Surface Mount Device Under 0.70mm Height
- Extremely Small Outline Plastic Package SOD523F
Device Marking Code
Device Type Device Marking
1N4148WT
E1
1N4448WT
E2
E3
- Moisture Level Sensitivity 1
- Pb-free Version and Ro HS pliant
- Matte Tin (Sn) Lead Finish
- Green Mold pound
Cathode
Anode
ELECTRICAL SYMBOL
SOD-523F Band Indicates Cathode
Absolute Maximum Ratings- TA=25°C unless otherwise noted
Symbol
Parameter
Value
VRSM
Non-Repetitive Peak Reverse Voltage
VRRM
Repetitive Peak Reverse Voltage
I FRM
Repetitive Peak Forward Current
TJ Operating Junction Temperature Range
-55 to +150
TSTG
Storage Temperature Range
- These ratings are limiting values above which the serviceability of any...
