74VCXH162835 - Low Voltage 18-Bit Universal Bus Driver

Fairchild Semiconductor

74VCXH162835 Datasheet Preview — Preview of 74VCXH162835 PDF

Datasheet Details

Part number	74VCXH162835
Manufacturer	Fairchild ↗ Semiconductor
File Size	98.69 KB
Description	Low Voltage 18-Bit Universal Bus Driver
Datasheet	74VCXH162835_FairchildSemiconductor.pdf

74VCXH162835 Product details

Description

The VCXF162835 low voltage 18-bit universal bus driver combines D-type latches and D-type flip-flops to allow data flow in transparent, latched and clocked modes.

Features

s Compatible with PC133 DIMM module specifications s 1.65V.
3.6V VCC specifications provided s 3.6V tolerant outputs s 26Ω series resistors in outputs s tPD (CP to On) 3.2 ns max for 3.0V to 3.6V VCC 4.1 ns max for 2.3V to 2.7V VCC 7.4 ns max for 1.65V to 1.95V VCC s Power-down high impedance outputs s Static Drive (IOH/IOL) ±12 mA @ 3.0V VCC ±8 mA @ 2.3V VCC ±3 mA @ 1.65V VCC s Latchup performance exceeds 300 mA s ESD performance: Human body model > 2000V Machine model >200V Ordering Co.
