ISL9V2040D3S Datasheet, Igbt, Fairchild Semiconductor

ISL9V2040D3S Features

• Igbt
• Space saving D - Pak package available
• SCIS Energy = 200mJ at TJ = 25oC
• Logic Level Gate Drive Package JEDEC TO-252AA JEDEC TO-263AB

PDF File Details

Part number:

ISL9V2040D3S

Manufacturer:

Fairchild Semiconductor

File Size:

321.85kb

Download:

📄 Datasheet

Description:

N-channel ignition igbt. The ISL9V2040D3S, ISL9V2040S3S, and ISL9V2040P3 are the next generation ignition IGBTs that offer outstanding SCIS capability in the

ISL9V2040D3S Application

• Applications
• Automotive Ignition Coil Driver Circuits
• Coil- On Plug Applications Features
• Space saving D - Pak package
