LM7905 - 3-Terminal 1A Negative Voltage Regulator

Fairchild Semiconductor

LM7905 Datasheet Preview — Preview of LM7905 PDF

Datasheet Details

Part number	LM7905
Manufacturer	Fairchild ↗ Semiconductor
File Size	227.10 KB
Description	3-Terminal 1A Negative Voltage Regulator
Datasheet	LM7905_FairchildSemiconductor.pdf

LM7905 Product details

Description

The KA79XX / KA79XXA / LM79XX series of three-terminal negative regulators are available in a TO-220 package with several fixed output voltages, making them useful in a wide range of applications.

Features

Output Current in Excess of 1 A.
Output Voltages of: -5 V, -6 V, -8 V, -9 V, -12 V, -15 V, -18 V, -24 V.
Internal Thermal Overload Protection.
Short-Circuit Protection.
Output Transistor Safe Operating Area Compensation.
