T93C66A, T93C46A-First - EEPROM

Datasheet Details

Part number	T93C66A, T93C46A-First
Manufacturer	First-Rank Technology
File Size	603.97 KB
Description	EEPROM
Datasheet	T93C46A-First-RankTechnology.pdf
Note	This datasheet PDF includes multiple part numbers: T93C66A, T93C46A-First. Please refer to the document for exact specifications by model.

FS-RANK Technology’s T93C family provides 1K, 2K and 4K of serial electrically erasable and programmable read-only memory (EEPROM).

Internally organized as 128 x 8 or 64 x 16(1K), 256 x 8 or 128 x 16 (2K), 512 x 8 or 256 x 16 (4K).
Wide-voltage range operation o 1.8V-5.5 V.
3-wire serial interface bus.
Data retention: 100 years.
High endurance: 1,000,000 Write Cycles.
2 MHz (5V) clock rate.
Sequential read operation.
Self-timed write cycle (10ms max).
8-pin PDIP, 8-pin JEDEC SOIC, and 8- pin TSSOP Packages.
