4, 1/2005 MC145026, MC145027 MC145028 MC145026, MC145027, MC145028 Encoder and Decoder Pairs CMOS 1 Introduction These devices are designed to be used as encoder/decoder pairs in remote control applications.
The MC145026 encodes nine lines of information and serially sends this information upon receipt of a transmit enable (TE) signal.
The nine lines may be encoded with trinary data (low, high, or open) or binary data (low or high).
The wo
