2MBI150XAA065-50 IGBT

2MBI150XAA065-50 Power Module (X series) 650V / 150A / 2-in-1 package * .

2MBI150XAA065-50-FujiElectric.pdf

2MBI150XAA065-50 Datasheet Preview — Preview of 2MBI150XAA065-50 PDF

Datasheet Details

Part number:

2MBI150XAA065-50

Manufacturer:

Fuji Electric

File Size:

514.07 KB

Description:

IGBT

Features

* Low V CE(sat) High speed switching Low Inductance Module structure

Applications

* Inverter for Motor Drives, AC and DC Servo Drives Uniterruptible Power Supply Systems, Industrial machines,such as Welding machines
* Outline drawing ( Unit : mm ) Characteristics indication IGBT Modules Weight: 180 g(typ. )
* Equivalent Circuit C1 G1 C1 (upper arm) E1 C2E1 G2 C2 (lo
