SMCJ58A, SMCJ6.0 Transient Voltage Suppressor

SMCJ58A Description

Transient Voltage Suppressor Production specification SMCJ5.0 *SMCJ440CA .

SMCJ58A Features

* Glass passivated junction
* Low incremental surge resistance, excellent clamping capability
* Underwriters Laboratory Recognition under UL standard
* for safety 497B: Isolated Loop Circuit Protection
* Low profile package with built-in strain relief for surface mounted applicat

SMCJ58A Applications

* 1500W peak pulse power capability with a 10/1000μs
* waveform, repetition rate (duty cycle): 0.01%
* Very fast response time
* High temperature soldering guaranteed: 250°C/10 seconds at terminals Mechanical Data
* Case: SMC molded plastic
* Molding compound, UL flammability

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: SMCJ58A, SMCJ6.0. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
SMCJ58A, SMCJ6.0
Manufacturer
GME
File Size
704.91 KB
Datasheet
SMCJ6.0-GME.pdf
Description
Transient Voltage Suppressor
Note
This datasheet PDF includes multiple part numbers: SMCJ58A, SMCJ6.0.
Please refer to the document for exact specifications by model.
