Part number:
5KP85A
Manufacturer:
GW
File Size:
72.13 KB
Description:
5000 watt axial lead tvs.
* 5000 Watts Surge Capability at 1ms
* Excellent clamping capability
* Low zener impedance
* Fast response time: Typically less than 1.0ps from 0 volt to BV min.
* Typical IR less than 1 A above 10V VOLTAGE RANGE 5.0 to 440 Volts 5000 Watts Peak Power R-6 .360(9.1) .340(8.6)
5KP85A
GW
72.13 KB
5000 watt axial lead tvs.
