BZW04P94 TRANSZORB TRANSIENT VOLTAGE SUPPRESSOR

BZW04P94 Description

BZW04P-5V8 THRU BZW04-376 TRANSZORB™ TRANSIENT VOLTAGE SUPPRESSOR Stand-off Voltage - 5.8 to 376 Volts DO204AL Peak Pulse Power - 400 Watts .

BZW04P94 Features

* Plastic package has Underwriters Laboratory Flammability Classification 94V-0
* Glass passivated chip junction
* 400W peak pulse power capability with a 10/1000µs waveform, repetition rate (duty cycle): 0.01%
* Excellent clamping capability
* Low incremental

BZW04P94 Applications

* For bi-directional use add suffix Letter "B" (e. g. BZW04P-6V4B). Electrical characteristics apply in both directions. MAXIMUM RATINGS AND CHARACTERISTICS Ratings at 25°C ambient temperature unless otherwise specified. SYMBOL VALUE UNITS Peak pulse power dissipation with a 10/1000µs waveform (NO

📥 Download Datasheet

Preview of BZW04P94 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
BZW04P94
Manufacturer
General Semiconductor
File Size
55.60 KB
Datasheet
BZW04P94_GeneralSemiconductor.pdf
Description
TRANSZORB TRANSIENT VOLTAGE SUPPRESSOR
