EGP30F - GLASS PASSIVATED FAST EFFICIENT RECTIFIER

Product Overview

General

Part number	EGP30F
Manufacturer	General
File Size	71.93 KB
Description	GLASS PASSIVATED FAST EFFICIENT RECTIFIER
Datasheet	EGP30F Datasheet
Additional preview pages of the EGP30F datasheet.

Plastic package has Underwriters Laboratories Flammability Classification 94V-0.
Glass passivated cavity-free junction.
Superfast recovery time for high efficiency.
Low forward voltage, high current capability.
Low leakage current.
High surge current capability.
High temperature metallurgically bonded construction.
High temperature soldering guaranteed: 300°C/10 seconds, 0.375" (9.5mm) lead length, 5 lbs. (2.3kg) tension P.
