MC34063 - DC/DC CONVERTER CONTROL CIRCUIT

Datasheet Summary

Description

The MC34063 is a monolithic control circuit containing the primary functions required for DC/DC converters.

The device consists of an internal temperature compensated reference, comparator, controlled duty cycle oscillator with an active current limit circuit, driver and high current output switch.

Features

  • 3V to 30V Input Voltage Operation.
  • Internal 1.2A Peak Current Switch.
  • Internal ±2% Reference.
  • Low Quiescent Current at 1.6mA.
  • Frequency Operation from 100Hz to 100KHz.
  • Low Dropout Operation: 100% Duty Cycle.
  • Current Limiting.
  • Standard SOP8/DIP8 Packages.

📥 Download Datasheet

Datasheet preview – MC34063

Datasheet Details

Part number MC34063
Manufacturer HOTCHIP
File Size 437.61 KB
Description DC/DC CONVERTER CONTROL CIRCUIT
Datasheet download datasheet MC34063 Datasheet
Additional preview pages of the MC34063 datasheet.

📁 Similar Datasheet

  • MC34063 - DC-DC CONVERTER CONTROLLER (ST Microelectronics)
  • MC34063 - DC to DC Converter Controller (Unisonic Technologies)
  • MC34063A - DC-DC Converter Controller (HTC)
  • MC34063A - DC-to-DC Converter Controller (Motorola)
  • MC34063A - Inverting Regulator (ON Semiconductor)
  • MC34063A - DC/DC CONVERTER CONTROLLER (AIC)
  • MC34063A - SMPS Controller (Fairchild)
  • MC34063A - DC-DC CONVERTER CONTROL CIRCUITS (STMicroelectronics)
  • MC34063A - DC TO DC CONVERTER CONTROLLER (UTC)
  • MC34063A - 1.5-A Peak Boost/Buck/Inverting Switching Regulators (Texas Instruments)
Other Datasheets by HOTCHIP

    Full PDF Text Transcription

    Click to expand full text
    MC34063 DC/DC CONVERTER CONTROL CIRCUIT Description The MC34063 is a monolithic control circuit containing the primary functions required for DC/DC converters. The device consists of an internal temperature compensated reference, comparator, controlled duty cycle oscillator with an active current limit circuit, driver and high current output switch. This device is specifically designed to be incorporated in stepdown, step-up and voltage-inverting applications with a minimum number of external components. The ±2% internal reference and low quiescent current of 1.6mA are among the improvements of the device over the competition Features  3V to 30V Input Voltage Operation.  Internal 1.2A Peak Current Switch.  Internal ±2% Reference.  Low Quiescent Current at 1.6mA.
