BT131
FEATURES
Symbol
Value
IT(RMS) V(DRM)/VRRM
1 600 to 800 l GT(Q1)
3 to 25
Unit A V m A
- GENERAL DESCRIPTION
The BTN01 series is suitable for general purpose AC switching applications. They can be found in applications such as home appliances (electro-valve, pump, door lock, small lamp control), fan speed controllers, Different gate current sensitivities are available, allowing optimized performances when controlled directly from micro-controllers.
- ABSOLUTE MAXIMUM RATINGS
Symbol
Parameter
IT(RMS)
ITSM l2T dl/dt l GM PG(AV) Tstg
Tj
RMS on-state current (full sine wave) Non repetitive surge peak on-state current (full cycle, Tj initial=25℃) I2T Value for fusing Critical rate of rise of on-state current IG=2 × IGT, tr≤100ns Peak gate current Average gate power dissipation Storage junction temperature range Operating junction temperature range
TO-92 F=50Hz F=60Hz tp=10ms
F=120Hz tp=20s
Tc=50℃ t=20ms t=16.7ms
Tj=125℃ Tj=125℃ Tj=125℃
Value
1 8 8.5 0.35
Unit A A A2s
20...
