M6A SURFACE MOUNT PLASTIC SILICON RECTIFIERS

M6A Description

SURFACE MOUNT PLASTIC SILICON RECTIFIERS .

M6A Features

* Diffused junction

M6A Applications

* Low reverse leakage current
* Low forward voltage drop
* High current capability
* Plastic material has UL flammability classification 94V-0 M1A thru M7A REVERSE VOLTAGE - 50 to 1000Volts FORWARD CURRENT - 1.0 Ampere A-SMA .087(2.21) .050(1.27) .181(4.60) .157(4.00) .114(2.90)

📥 Download Datasheet

M6A Datasheet Preview — Preview of M6A PDF

Datasheet Details

Part number: M6A
Manufacturer: HY
File Size: 40.72 KB
Datasheet: M6A-HY.pdf
Description: SURFACE MOUNT PLASTIC SILICON RECTIFIERS
