HDSP-4850, HDSP-4820_Hewlett - (HDSP-48xx) 10-Element Bar Graph Array

Hewlett-Packard

📥 Download Datasheet

HDSP-4850 Datasheet Preview — This datasheet PDF includes multiple part numbers: HDSP-4850, HDSP-4820_Hewlett. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	HDSP-4850, HDSP-4820_Hewlett
Manufacturer	Hewlett-Packard
File Size	180.04 KB
Description	(HDSP-48xx) 10-Element Bar Graph Array
Datasheet	HDSP-4820_Hewlett-Packard.pdf
Note	This datasheet PDF includes multiple part numbers: HDSP-4850, HDSP-4820_Hewlett. Please refer to the document for exact specifications by model.

HDSP-4850 Product details

Description

These 10-element LED arrays are designed to display information in easily recognizable bar graph form.

Features

Custom Multicolor Array Capability.
Matched LEDs for Uniform Appearance.
End Stackable.
Package Interlock Ensures Correct Alignment.
Low Profile Package.
Rugged Construction.
Large, Easily Recognizable Segments.
High ON-OFF Contrast, Segment to Segment.
Wide Viewing Angle.
Categorized for Luminous Intensity.
HDSP-4832/4836/4840/4850 Categorized for Dominant Wavelength.
HLCP-J100 Operates.
