SC3D20120D
Features
Applications
- 1200-Vol t Schottky Recti fier
- Zero Reverse Recovery Current
- Zero Forwa rd Recovery Vol tage
- Hi gh-Frequency Operation
- Temperature-Independent Switching Beha vior
- Extremel y Fast Switching
- Posi ti ve Tempera ture Coefficient on VF
Benefit s
- Swi tch Mode Power Supplies(SMPS)
- Boost diodes in PFC or DC/DC stages
- Free wheeling diodes in inverter stages
Package
- Replace Bipolar wi th Unipola r Rectifiers
- Essentiall y No Swi tching Losses
- Hi gher Effi ciency
- Reduction of Hea t Sink Requi rements
Part Number
Package
- Pa rallel Devi ces Wi thout Thermal Runawa y
TO-247-3
Maximum Ratings (TC=25℃ unless otherwise specified)
Marking C3D20120
Symbol
Parameter
Value
Unit
Test Conditions
VRRM Repetiti ve Peak Reverse Vol tage
VRSM Surge Peak Reverse Vol tage
VDC DC Blocking Volta ge
Continuous Forwa rd Current IF
(Per Leg/Devi ce)
53/106 17/34 10/20
TC=25℃ A TC=135℃
TC=150℃...
