HD4074008H

Two timer/counters

HD4074008H Features

* 35 I/O pins, including nine high-current pins (15 mA, max.), eight pins multiplexed with LCD segment pins, and four pins multiplexed with analog input pins

* Four timer/counters

* Eight-bit input capture circuit

* Three timer outputs (including two PWM outputs)

HD4074008H General Description

The HD404849 series of HMCS400-series microcomputers is designed to increase program productivity and also incorporate large-capacity memory. Each microcomputer has an LCD controller/driver, A/D converter, input capture circuit, 32-kHz oscillator for clock use, and four low-power dissipation modes. .

HD4074008H Datasheet (471.95 KB)

Preview of HD4074008H PDF

Datasheet Details

Part number:

HD4074008H

Manufacturer:

Hitachi Semiconductor

File Size:

471.95 KB

Description:

Two timer/counters.
