HD74LS04 - (HD74LS04 / HD74LS05) Hex Inverters(with Open Collector Outputs)

Datasheet Summary

Features

  • Ordering Information.
  • HD74LS04 Part Name HD74LS04P www. DataSheet4U. com Package Type DILP-14 pin SOP-14 pin (JEITA) SOP-14 pin (JEDEC) Package Code (Previous Code) PRDP0014AB-B (DP-14AV) PRSP0014DF-B (FP-14DAV) PRSP0014DE-A (FP-14DNV) Package Abbreviation P FP RP Taping Abbreviation (Quantity).
  • EL (2,000 pcs/reel) EL (2,500 pcs/reel) HD74LS04FPEL HD74LS04RPEL.
  • HD74LS05 Part Name HD74LS05P HD74LS05FPEL HD74LS05RPEL Package Type DILP-14 pin SOP-14 pin (JEI.
