C17F05071

Multiscanning Color Monitor TECHNICAL SERVICE MANUAL

C17F05071 Datasheet (4.22 MB)

Preview of C17F05071 PDF Datasheet

Datasheet Details

Part number:

C17F05071

Manufacturer:

Hyundai

File Size:

4.22 MB

Description:

Multiscanning color monitor technical service manual

C17F05071 Features

* identified by " ! " in the replacement parts list and schematic diagram. For continued protection, replacement parts must be identical to those used in the original circuit. The use of substitute replacement parts which dose not have the same safety characteristics as the factory recommended replace

C17F05071 General Description

This 17" (16" viewable) color display monitor is operated in R, G, B, drive mode input. 2. Operating instructions 2-1. Front DPMS(Power)LED, Soft Power. Menu, Select,Down 2-2. Rear Input connection AC & SIGNAL CABLE 2-3 Service Instruction(internal controls) H-Center , H/V Focus 2-4. OSD Controls B.
