MBR4045CT
FEATURES
- With TO-220 packaging
- High junction temperature capability
- Low forward voltage drop
- High current capability
- Low power loss, high efficiency
- Minimum Lot-to-Lot variations for robust device performance and reliable operation
APPLICATIONS
- Switching power supply
- Free-Wheeling diodes
- Reverse battery protection
- Center tap configuration
ABSOLUTE MAXIMUM RATINGS(Ta=25℃)
SYMBOL
PARAMETER
VALUE
UNI T
VRRM VRWM
Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage
IF(AV)
Average Rectified Forward Current@Tc=150℃
Nonrepetitive Peak Surge Current
IFSM
（ 8.3ms single half sine-wave superimposed 900
A on rated load conditions）tp=5μs sine
Junction Temperature
℃
Tstg
Storage Temperature Range
-65~150 ℃
MBR4045CT isc website：.iscsemi.
1 isc & iscsemi is registered trademark
Schottky Barrier Rectifier
THERMAL CHARACTERISTICS
SYMBOL...
