DSSK 20-0045A
www.DataSheet4U.com
Power Schottky Rectifier
with common cathode
IFAV = 2x10 A VRRM = 45 V VF = 0.58 V
VRSM V 45
VRRM V 45
Type
A C A
TO-220 AB
A C A
DSSK 20-0045A
C (TAB)
A = Anode, C = Cathode , TAB = Cathode
Symbol IFRMS IFAV IFAV IFSM EAS IAR (dv/dt)cr TVJ TVJM Tstg Ptot Md Weight
Conditions TC = 160°C; rectangular, d = 0.5 TC = 160°C; rectangular, d = 0.5; per device TVJ = 45°C; tp = 10 ms (50 Hz), sine IAS = 13 A; L = 180 µH; TVJ = 25°C; non repetitive VA =1.5 • VRRM typ.; f=10 kHz; repetitive
Maximum Ratings 35 10 20 140 24 1.3 1000 -55...+175 175 -55...
DSSK20-0045A Datasheet
