IXFR10N100F Datasheet, MOSFETs, IXYS Corporation

IXFR10N100F Features

• Mosfets z RF capable MOSFETs z Double metal process for low gate resistance z Unclamped Inductive Switching (UIS) rated z Low package inductance - easy to drive and to protect z Fast intrinsic

PDF File Details

Part number:

IXFR10N100F

Manufacturer:

IXYS Corporation

File Size:

91.92kb

Download:

📄 Datasheet

Description:

Hiperfet power mosfets.

IXFR10N100F Application

• Applications z DC-DC converters z Switched-mode and resonant-mode power supplies, >500kHz switching z DC choppers z 13.5 MHz industrial applications
